Description Phantom Flex 4K SENSOR SPECIFICATIONS CMOS sensor 4096 x 2304 pixels 6.75 µm pixel size 27.6 mm x 15.5 mm Super-35mm; 31.7mm diagonal Super-16mm format at 1920 x 1080 Base ISO Color 200 D Exposure index range 200-1250 Recommended EI 800-1000 Color Base ISO Monochrome 800 D 12-bit MEMORY 32, 64, or 128GB high-speed internal RAM CineMag IV for non-volatile storage (1TB, 2TB) RECORD TIMES 5 seconds at 1000 fps, 4096 x 2160 resolution and into 64 GB of internal memory 2TB CineMag IV holds 2 hours of 4K Cine raw playback at 24p 2TB CineMag IV holds over 4 hours of 4K ProRes HQ playback at 30p FRAME RATES 4096 x 2304, 938 4096 x 2160, 1000 2048 x 1080, 1977 1280 x 720, 2932 TRIGGERING Programmable trigger location (pre/post trigger recording) Trigger from camera body or via software Hardware trigger via Sync port Trigger inputs also available on 3-pin accessory ports ETHERNET CONNECTION Gb Ethernet for both control and data 10Gb Ethernet on CineStation IV CAMERA CONTROL Phantom Camera Control (PCC) On-Camera Controls Remote Control Unit (RCU), connects direct to camera SDK available SUPPORTED FILE FORMATS Cine raw and Apple ProRes 422 HQ CineMag recording PCC Cine file conversion to: Cine Compressed Cine RAW, AVI, h.264 mp4, Apple ProRes .mov Multipage TIFF, MXF PAL, MXF NTSC Uncompressed QuickTime, Windows BMP, OS/2 BMP, PCX, TGA, TIFF, LEAD, JPEG, JTIF, RAW, DNG, DPX MECHANICAL SPECIFICATIONS Size (without lens or viewfinder): 12 x 6 x 8 in. (L x W x H); 30.5 x 35.5 x 20.3 cm. Weight (without lens or viewfinder): 13 lbs; 5.9 kg
